Mackie SRM350V3 10" Powered Loudspeaker

The Mackie SRM350V3 is a portable 10-inch powered loudspeaker designed for live sound, presentations, rehearsal spaces, mobile DJs, and small performance systems. Its built-in amplification removes the need to match and transport an external power amplifier. With two onboard input channels, it can serve as a compact standalone PA speaker or as part of a larger sound setup.

This speaker is suited to performers, event hosts, venues, and audio providers who need clear, practical reinforcement in a manageable enclosure. The 10-inch woofer and 1.4-inch titanium-diaphragm compression driver are paired in a two-way design. Its frequency response and wide horizontal coverage support speech, vocals, music playback, and stage-monitor duties.

The SRM350V3 uses 500 watts RMS of system amplification, rated at 1,000 watts peak, with separate low- and high-frequency amplifier sections. Mackie High-Definition Audio Processing includes acoustic correction, driver time alignment, and phase correction. A 3 kHz crossover divides the signal between the woofer and compression driver.

Four selectable Speaker Modes provide application-specific processing for PA, DJ, Monitor, and Soloist use. The automatic Feedback Destroyer is designed to help reduce feedback during live microphone use. Smart Protect DSP adds peak and RMS limiting along with power-supply and amplifier thermal protection.

For system expansion, the integrated two-channel mixer accepts microphones, instruments, mixers, and stereo RCA music sources. A balanced XLR Thru output can pass Channel 1 or the mixed signal to another compatible speaker or device. Use the SRM350V3 on the floor, on a suitable speaker pole, or with the optional SRM350V3 bracket for fixed installation.

Key Features

• 500W RMS System Amplification: Built-in two-way amplification eliminates the need for a separate power amp.
• 10-Inch Two-Way Design: A paper-cone woofer and titanium compression driver cover full-range sound duties.
• Four Speaker Modes: PA, DJ, Monitor, and Soloist modes tailor voicing for common applications.
• Feedback Destroyer: Automatic filtering helps manage feedback in microphone-based setups.
• Integrated Two-Channel Mixer: Two Wide-Z inputs and stereo RCA inputs accommodate multiple sources.
• Balanced XLR Thru Output: Send Channel 1 or the mixed signal onward to compatible equipment.

Design & Installation

The SRM350V3 uses a polypropylene cabinet with a black textured finish and a perforated metal grille with a weather-resistant coating. Its 50-degree monitor angle supports floor-wedge placement, while the 23-pound enclosure remains practical for portable applications. The cabinet measures 20.8 inches high, 13.1 inches wide, and 12.3 inches deep.

Connect AC power with the detachable line cord, then connect microphones, instruments, mixers, or music sources to the appropriate inputs and set gain carefully. For a main PA position, place the speaker on a stable floor or compatible speaker pole; for monitoring, use its angled cabinet orientation. An optional SRM350V3 bracket is required for fly installation, and a balanced XLR cable may be used from the Thru output to feed another compatible device.
