Memphis MJME6D1TV2 Dual 6.5" Ported Truck Subwoofer

The Memphis Audio MJME6D1TV2 is a loaded, ported truck-style subwoofer enclosure with two 6.5-inch MOJO Mini subwoofers. It is designed for adding bass where conventional large enclosures may not fit, especially behind the seat of many single-cab trucks. The enclosure presents one 1-ohm final load at its spring-post input terminals.

This model is intended for vehicle owners building a compact bass system without separately selecting and installing an enclosure and pair of woofers. Its thin-profile shape is made for space-limited locations, while the ported cabinet is tuned for strong low-frequency output. The loaded design also simplifies the physical speaker-and-box portion of a subwoofer upgrade.

With 1,400 watts RMS and 2,800 watts peak power handling for the complete enclosure, the MJME6D1TV2 is suited to an appropriately matched external amplifier. Its stated frequency response is 48-150 Hz, focusing its role on bass reproduction rather than full-range playback. The two drivers are wired in parallel to provide the enclosure's 1-ohm final impedance.

MOJO Mini driver construction includes fiberglass-reinforced cones, stitched foam surrounds, vented cast-aluminum baskets, and 4-layer wound copper voice coils. Memphis DVVC Direct Vent Voice Coil Cooling and aluminum heat-sink elements are incorporated to help manage heat during demanding playback. These features support the enclosure's compact, high-power design.

The carpet-wrapped cabinet gives the installation a finished appearance while helping protect the enclosure surface from everyday scuffs. Its 36.1-inch width, 14.2-inch height, 3.5-inch top depth, and 7.5-inch bottom depth should be measured against the intended vehicle location before purchase. Use it with a compatible amplifier, suitable power wiring, and a secure mounting plan for a complete bass upgrade.

Key Features

• Dual 6.5-Inch MOJO Mini Drivers: Two compact subwoofers share one loaded enclosure for space-conscious bass installations.
• Ported Truck Enclosure: The vented cabinet design is intended for higher-output bass performance in a shallow profile.
• 1-Ohm Final Impedance: The two 2-ohm drivers are factory wired in parallel at the enclosure terminals.
• 1,400-Watt RMS Handling: Supports use with an external amplifier matched to the enclosure's continuous rating and impedance.
• DVVC Cooling System: Direct voice-coil venting and aluminum heat-sink elements help manage operating heat.
• Carpet-Wrapped Finish: The finished exterior is designed for a clean appearance in truck and custom vehicle installations.

Design & Installation

The MJME6D1TV2 uses a ported, carpet-wrapped enclosure loaded with two MOJO Mini subwoofers. Driver details include fiberglass-reinforced cones, stitched foam surrounds, vented cast-aluminum baskets, and 4-layer wound copper voice coils. The enclosure is a thin-profile truck-box design with a 3.5-inch top depth and 7.5-inch bottom depth.

Confirm available mounting space before installation, particularly the 36.1-inch width and 14.2-inch height. Connect an amplifier that is designed to operate at the enclosure's 1-ohm final impedance, using speaker wire up to 10 AWG at the single spring-post terminal set. The included mounting brackets and hardware can be used to secure the enclosure; no amplifier is included with the listed package contents.
