Memphis MJM612 6.5" MOJO Mini Selectable-Impedance Subwoofer

The Memphis MJM612 is a 6.5-inch MOJO Mini component subwoofer designed for car-audio systems that need substantial bass output from a compact driver. Its selectable 1-ohm or 2-ohm configuration helps match the subwoofer to an amplifier and system design. It is intended for custom enclosure installations rather than direct replacement of a factory door speaker.

With a 700-watt RMS power rating and 1,400-watt peak rating, the MJM612 is suited to systems built around a properly matched mono amplifier. Its compact diameter can help when available enclosure space is limited, while its 5-inch mounting depth should still be verified before installation. The 6.5-inch format can be used singly or in multi-subwoofer installations.

Memphis FLEX selectable-impedance technology allows the MJM612 to be configured for either a 1-ohm or 2-ohm load. This provides system-planning flexibility when pairing the subwoofer with an amplifier that is stable at the selected impedance. Confirm amplifier load capability and configure the subwoofer before final wiring.

The MJM612 uses a V-Groove stitched foam surround to increase usable cone area and support excursion in its compact frame. A 4-layer copper 1.5-inch voice coil, DVVC direct-vent voice-coil cooling, and an aluminum heat sink are used to manage heat during demanding playback. These construction details support its high-power design.

A vented cast-aluminum basket provides a rigid mounting structure, while the fiberglass-reinforced dust cap and foam surround complete the moving assembly. Memphis publishes enclosure recommendations for sealed and vented applications, allowing the driver to be used in a compact custom build. Choose the enclosure type, internal volume, port specification, and amplifier setting according to the intended system design.

Key Features

• FLEX Selectable Impedance: Configures for a 1-ohm or 2-ohm load.
• 700W RMS Power Handling: Supports use with a properly matched amplifier.
• DVVC Cooling: Direct voice-coil venting helps dissipate operating heat.
• V-Groove Foam Surround: Supports cone movement in a compact subwoofer.
• Cast Aluminum Basket: Provides a rigid, vented driver frame.
• 1.5-Inch Copper Voice Coil: Uses a four-layer copper winding design.

Design & Installation

The MJM612 combines a vented cast-aluminum basket with a fiberglass-reinforced dust cap, stitched foam surround, aluminum heat sink, and 80-ounce magnet. Its 1.5-inch, four-layer copper voice coil uses Memphis DVVC cooling. The driver has a 7.05-inch outside frame diameter, a 5.95-inch cutout requirement, and a 5-inch mounting depth.

Install the MJM612 in a properly built sealed or vented enclosure that meets Memphis volume recommendations. A single sealed enclosure is specified at 0.5 cubic feet gross, while a single vented enclosure is specified at 0.8 cubic feet gross and 40 Hz tuning. Select the 1-ohm or 2-ohm configuration only with an amplifier that supports that final load, and set gain conservatively to avoid clipping or distortion.
