Zoom SSH-6e Stereo Shotgun Microphone Capsule

The Zoom SSH-6e is a Mid-Side stereo shotgun microphone capsule made for focused dialogue and location recording with compatible Zoom Handy Recorders. It combines a highly directional mid microphone with a bidirectional side microphone, helping capture a subject clearly while retaining controlled environmental sound. This approach is useful for video production, interviews, documentary work, and other recordings where direct sound and ambience both matter.

The capsule's mid microphone uses a supercardioid polar pattern to focus on sound in front of the recorder. Its side microphone captures the lateral information needed to create a stereo image. By adjusting the recorder's side-mic level, users can set a tighter, more focused image or introduce a wider sense of space.

For a straightforward dialogue setup, the side level can be muted so the SSH-6e operates as a mono shotgun microphone. When recording in Raw Mid-Side mode, the stereo width can instead be adjusted later in a DAW with Zoom's MS Decoder software. This gives field recordists flexibility to make stereo decisions during recording or in post-production.

The SSH-6e uses Zoom Capsule System 3.0, the connection platform designed for the H6essential, H5studio, and H6studio recorders. With a compatible recorder that supports 32-bit float recording, the system is ready to capture a broad range of sound levels without manual input-gain adjustment. Firmware requirements apply for each compatible recorder model.

Compact and lightweight, the SSH-6e fits directly onto the compatible recorder's capsule connection rather than requiring a separate cable or external microphone mount. A WSU-2 hairy windscreen is included to help reduce wind interference during outdoor work. It is a practical upgrade for users who need a more focused pickup pattern than a standard stereo capsule while preserving adjustable stereo ambience.

Key Features

• Mid-Side Stereo Design: Combines focused direct pickup with adjustable ambient stereo capture.
• Supercardioid Mid Microphone: Concentrates on sound arriving from the front.
• Bidirectional Side Microphone: Captures side information for an adjustable stereo image.
• Adjustable Stereo Width: Recorder side-level control changes the apparent width.
• Raw Mid-Side Recording: Allows later width adjustment with MS Decoder software.
• WSU-2 Windscreen Included: Helps reduce wind noise during outdoor recording.

Design & Installation

The SSH-6e is a compact interchangeable microphone capsule measuring 53.2 mm wide, 138.6 mm deep, and 38.1 mm high. It weighs 43 g and uses Zoom's Capsule System 3.0 connection for a stable direct fit on supported recorders. Its two-microphone Mid-Side arrangement places the supercardioid mid mic and bidirectional side mic in one integrated capsule.

Install the SSH-6e directly on a compatible H6essential, H5studio, or H6studio recorder after confirming the recorder firmware meets Zoom's stated requirement. Set the recorder's side level to control the stereo width, select Mute for mono shotgun operation, or use Raw Mid-Side recording when you want to decode and adjust width later in a DAW. Fit the included WSU-2 hairy windscreen for outdoor recording where wind noise may affect the capture.
