Rockford Fosgate T1S1-10S 10" 1-Ohm Slim Subwoofer

The Rockford Fosgate T1S1-10S is a 10-inch shallow-mount subwoofer made for vehicle audio systems where mounting depth is limited. Its sealed-enclosure design helps make compact bass upgrades practical in truck cabs, behind-seat installations, and other confined spaces. It is sold as one individual subwoofer.

This model uses a single 1-ohm voice coil and is rated for 500 watts RMS, with 1,000 watts maximum power handling. It is intended for use with an amplifier that is designed to operate safely at a 1-ohm speaker load. The shallow 3.01-inch mounting depth helps preserve usable vehicle space while accommodating a substantial woofer assembly.

The T1S1-10S is optimized for compact sealed enclosures, with a recommended net enclosure volume of 0.5 to 0.75 cubic feet. A sealed enclosure can suit listeners seeking controlled low-frequency response in a compact box. Rockford Fosgate does not recommend a vented enclosure for this sealed-specific version.

Its moving assembly combines a carbon fiber, PMI, and glass-fiber cone with an aluminum dustcap and a molded polymer surround. The surround uses Nano Cell Direct Injection construction and is chemically bonded to the cone assembly. Dual progressive Nomex spiders and stitched tinsel leads support controlled movement and durability.

Thermal management is central to the T1 Slim design. The subwoofer uses a dual-wound 2.5-inch pure-copper single voice coil on a composite former, along with an aluminum spider spacer and die-cast aluminum basket heat-sink fins. These construction details support power handling in a shallow-format subwoofer for a system built around compact sealed bass.

Key Features

• Shallow 10-Inch Design: Fits installations with only 3.01 inches of mounting depth.
• 1-Ohm Single Voice Coil: Provides a nominal 1-ohm load for compatible amplifiers.
• 500-Watt RMS Rating: Supports amplifier matching for sustained subwoofer power.
• Sealed-Box Optimization: Designed for compact sealed enclosures from 0.5 to 0.75 cubic feet.
• Composite Cone Assembly: Carbon fiber, PMI, and glass fiber help support rigid cone behavior.
• Advanced Cooling Construction: Composite former, copper coil, spacer, and heat-sink basket manage heat.

Design & Installation

The T1S1-10S uses a die-cast aluminum frame with integrated heat-sink fins, a high-energy neodymium motor structure, and corrosion-resistant tin-plated brass spring terminals. Its cone assembly includes a linear carbon fiber, PMI, and glass-fiber cone with an aluminum dustcap. A detachable die-cast aluminum trim ring is fitted, while a matching protective grille insert is available separately.

Plan the enclosure around the manufacturer-recommended 0.5 to 0.75 cubic feet sealed net volume and account for the woofer's 0.028 cubic-foot displacement. The mounting cutout requires a 9.13-inch diameter opening, and the enclosure must provide at least 3.01 inches of mounting depth. Use appropriately sized speaker cable with the 10 AWG slot-loaded terminals and pair the woofer with an amplifier rated for a 1-ohm load.
