Memphis SRX62V 6.5" 2-Way Coaxial Speakers

The Memphis SRX62V is a pair of 6.5-inch, 2-way coaxial car speakers designed to replace worn or limited factory door or rear-deck speakers. It provides an approachable path to a more capable everyday audio system while retaining a conventional full-range speaker format. The pair is suited to vehicle owners who need a compact replacement speaker with clearly stated mounting dimensions.

Each SRX62V combines a polypropylene cone woofer with a PEI tweeter in a coaxial layout. This arrangement places high-frequency reproduction at the center of the main driver, helping consolidate midrange and treble output into one speaker location. The rubber surround supports the cone assembly and is part of the speaker's updated Street Reference construction.

Memphis rates the SRX62V at 50 watts RMS and 100 watts peak power per speaker, with 90 dB sensitivity. Those ratings make it appropriate for a factory-radio replacement system or for use with an amplifier matched to the speaker's continuous power rating. Its 2-way design supplies both main-driver and tweeter reproduction without requiring a separate external tweeter installation.

A slim 1.74-inch mounting depth is a practical advantage where door depth is limited. The specified 4.8-inch cutout diameter gives installers a starting point for checking the factory opening before purchase. As with any vehicle speaker replacement, mounting pattern, panel clearance, and connector compatibility should be verified for the specific vehicle.

The SRX62V fits naturally into a basic speaker refresh or a larger Street Reference system upgrade. It can be used as a matching pair in front or rear locations where a 6.5-inch round speaker is appropriate. Optional SRXG62 grilles are available separately for installations that need added speaker protection or a finished appearance.

Key Features

• 6.5-Inch Coaxial Pair: Replaces compatible round factory speaker locations with a matched left/right pair.
• 2-Way Design: Combines a woofer and PEI tweeter in each speaker.
• Polypropylene Cone: Provides the main woofer diaphragm material for everyday playback.
• Rubber Surround: Supports controlled cone movement in the woofer assembly.
• 50-Watt RMS Rating: Supports amplifier matching using a continuous power specification.
• Slim Mounting Profile: The 1.74-inch depth helps fit shallower mounting locations.

Design & Installation

The SRX62V uses a polypropylene cone, PEI tweeter, and rubber surround in a compact coaxial speaker assembly. Memphis lists the model in its Street Reference speaker range and specifies an 11-ounce magnet. Grilles are not included with this model, though the separately available SRXG62 grille is designated for the 6.5-inch size.

Confirm that the vehicle accepts a 6.5-inch round speaker and that the opening accommodates the 4.8-inch cutout diameter before installation. Measure available mounting clearance against the 1.74-inch mounting-depth specification and verify the factory mounting pattern and wiring connection. For amplified systems, select amplification with output matched appropriately to the 50-watt RMS rating per speaker.
