Memphis MB1024 10" Selectable-Impedance Subwoofer

The Memphis MB1024 is a 10-inch car audio subwoofer designed for systems that need meaningful low-frequency output while retaining installation flexibility. Its selectable impedance design allows the same subwoofer to be configured for either 2-ohm or 4-ohm operation. This makes it a practical choice for replacing an existing woofer or planning a system around a compatible mono amplifier.

With a 500-watt RMS power rating and 1,000-watt peak rating, the MB1024 is intended for a properly matched amplified subwoofer system. It is suited to listeners who want fuller bass response than factory speakers can provide. The 10-inch format can fit where larger subwoofers may not be practical, provided enclosure and mounting-clearance requirements are met.

Memphis FLEX selectable impedance technology is the defining feature of this model. It gives installers the option to configure the subwoofer for 2-ohm or 4-ohm use, helping align the woofer with an amplifier's stable operating load. Sensitivity is rated at 84.6 dB in the 2-ohm configuration and 85.3 dB in the 4-ohm configuration.

The MB1024 uses an ultra-light aluminum voice coil, a 2-inch four-layer triple voice coil design, and DVVC direct vented voice coil cooling. These elements support power handling and help manage heat during operation. Woven tinsel leads and a polypropylene dust cap complete the working assembly.

A double-stitched V-Groove folded surround is used to support increased excursion while preserving effective cone area. Memphis provides sealed and vented enclosure recommendations for single- and dual-subwoofer applications. Pair the MB1024 with a suitable enclosure, correctly configured amplifier, and appropriately sized wiring for a focused bass upgrade.

Key Features

• FLEX Selectable Impedance: Choose 2-ohm or 4-ohm operation to suit a compatible amplifier.
• 500W RMS Handling: Supports properly matched amplified bass systems.
• 10-Inch Driver: Provides a compact format for vehicle subwoofer installations.
• Aluminum Voice Coil: Supports sensitivity and output with low moving mass.
• DVVC Cooling: Direct venting helps manage voice-coil heat during operation.
• Folded V-Groove Surround: Supports excursion while retaining effective surface area.

Design & Installation

The MB1024 combines a polypropylene dust cap, woven tinsel leads, ultra-light aluminum voice coil, and double-stitched V-Groove folded surround. Its 2-inch, four-layer triple voice coil and 60-ounce magnet are matched with DVVC direct vented voice coil cooling. The subwoofer has a 10.16-inch outside frame diameter, a 9.17-inch cutout requirement, and a 5.14-inch mounting depth.

Confirm that the enclosure has at least the required cutout diameter and mounting depth before installation. Memphis recommends a 1.0-cubic-foot sealed enclosure for one subwoofer or a 1.5-cubic-foot gross vented enclosure tuned to 38 Hz; dual-subwoofer recommendations are also available. Configure the selectable impedance setting to match an amplifier that is designed to operate safely at the chosen load.
