Hifonics BRL2000.1 Brutus 2000W Mono Car Amplifier

The Hifonics Brutus BRL2000.1 is a mono car audio amplifier designed to power a subwoofer system with substantial output from a compact chassis. It is rated to deliver up to 2,000 watts RMS into a 1-ohm load, with additional power ratings for 2-ohm and 4-ohm systems. It is intended for universal vehicle installation and works as a dedicated low-frequency amplifier.

This amplifier is suited to listeners building or upgrading a bass-focused system that needs a single mono channel. Its variable crossover controls and bass boost allow the subwoofer output to be tailored to the rest of the audio system. A wired bass remote is included for convenient level adjustment from the driver's seat.

The BRL2000.1 uses Hifonics Super D Class topology and a half-bridge design intended to support efficient power delivery. Its iron-core transformer and ultra-low EMI-oriented power supply design are engineered to help reduce interference with vehicle electronics. Ultra-Fi MOSFET output devices and a mass-loaded extruded aluminum heat sink support output performance and thermal management.

A selectable illuminated logo provides constant blue lighting, VU meter operation, or an off setting. In VU meter mode, the logo responds to audio level and can assist with gain adjustment. The amplifier also includes delayed turn-on circuitry to help minimize unwanted turn-on and turn-off noise.

The BRL2000.1 fits into a system using RCA-level signal connections and a properly matched subwoofer load. Its secure molded power, ground, and speaker terminals are angled for access and cleaner wire routing. Built-in protection circuits monitor over- and under-voltage, short circuit, overcurrent, and thermal conditions.

Key Features

• 2,000W RMS at 1 Ohm: Provides high-output mono amplification for a properly matched subwoofer system.
• Super D Class Topology: Supports efficient power delivery in a compact mono amplifier design.
• Selectable VU Meter Logo: Offers blue illumination, audio-responsive VU operation, or an off setting.
• Variable Electronic Crossovers: Lets you adjust high-pass and low-pass filtering for system integration.
• Included Bass Remote: Allows remote adjustment of bass level relative to the amplifier setting.
• Triple Protection Circuits: Includes safeguards for voltage, current, short-circuit, and thermal conditions.

Design & Installation

The BRL2000.1 has a black chassis with a mass-loaded extruded aluminum heat sink for thermal management. Its multi-layer printed circuit board uses surface-mount components for a clean internal layout. Nickel-plated RCA inputs are designed for corrosion-resistant signal connections, while the molded terminals provide dedicated power, ground, and speaker connection points.

Mount the amplifier securely in a location with ventilation and access to its controls and terminals. Use appropriately sized power, ground, speaker, and external fuse wiring; the amplifier accepts 2 AWG power and ground cable and 12 AWG speaker wire. Match the subwoofer wiring to a supported 1-ohm, 2-ohm, or 4-ohm load, then set gain, crossover, and bass boost carefully during system tuning.
