Cerwin-Vega V10DV2 10" Dual 2-Ohm Voice Coil Subwoofer

The Cerwin-Vega V10DV2 is a 10-inch car audio subwoofer designed to add dedicated low-frequency output to an upgraded vehicle sound system. Its dual 2-ohm voice coil configuration provides wiring flexibility for compatible mono or multi-channel amplifiers. It is intended for listeners building a bass-focused system rather than relying on factory full-range speakers for low-end reproduction.

With a 1,000-watt RMS power rating and 3,000-watt maximum rating, the V10DV2 is built for systems using substantial amplifier power. Its 85 dB sensitivity and 45 Hz free-air resonance describe a subwoofer engineered around controlled bass reproduction in an appropriately designed enclosure. Proper gain setting and amplifier load compatibility remain important for reliable operation.

The V10DV2 uses a hybrid carbon fiber and polypropylene cone with a stitch-reinforced Santoprene surround. This combination is designed to keep the moving assembly stable while accommodating bass excursion. A ferrite motor structure supplies the magnetic drive behind the woofer.

A vented pole piece supports heat management during extended playback, while the 3-inch voice coil is sized for high-power use. The subwoofer also uses a single terminal impedance selector to simplify connection of its dual voice coils. When wired in parallel, its dual 2-ohm coils present a 1-ohm load; series wiring presents a 4-ohm load.

This subwoofer fits custom sealed or ported car audio builds when the enclosure and amplifier are selected for the vehicle and desired output. Its 5.94-inch mounting depth and 9.17-inch cutout requirement should be checked before installation. It can serve as a single-subwoofer upgrade or as part of a multi-subwoofer system with appropriate impedance planning.

Key Features

• Dual 2-Ohm Voice Coils: Supports 1-ohm parallel or 4-ohm series wiring configurations.
• 1,000W RMS Handling: Accommodates high-power amplification when configured and tuned correctly.
• Hybrid Cone Construction: Carbon fiber and polypropylene construction supports stable cone movement.
• Santoprene Surround: Stitch-reinforced surround supports excursion and long-term durability.
• Vented Pole Piece: Helps manage heat during extended high-output playback.
• Single Terminal Selector: Simplifies access to the dual-voice-coil wiring configuration.

Design & Installation

The V10DV2 combines a cast aluminum basket, ferrite magnet structure, polypropylene-based cone construction, and Santoprene surround. Its 3-inch voice coil, vented pole piece, and concealed mounting gasket are part of a design focused on high-power car audio use. The overall diameter is 10.89 inches, with an overall height of 6.69 inches.

Confirm available mounting space before cutting, using the 9.17-inch cutout diameter and 5.94-inch mounting-depth requirements. Both voice coils must be connected to an amplifier, and the amplifier must be stable at the final wired impedance. Use a properly designed subwoofer enclosure and set amplifier gain conservatively to avoid speaker damage.
