Cerwin Vega VMAX15D2 15" Dual 2-Ohm Subwoofer

The Cerwin Vega VMAX15D2 is a 15-inch dual 2-ohm car subwoofer designed for systems that need substantial low-frequency output. It is rated for 1,500 watts RMS and 3,000 watts maximum power handling. This model is intended for custom car-audio installations using an external amplifier and enclosure.

Its dual 2-ohm voice-coil design gives installers flexibility when matching the subwoofer to an amplifier. The coils can be configured for 1-ohm or 4-ohm nominal system wiring, provided the amplifier is stable at the selected load. This makes the VMAX15D2 suitable for single-subwoofer builds where amplifier compatibility is an important consideration.

The VMAX15D2 uses a treated semi-pressed pulped cone and treated foam surround to support controlled cone movement. With a listed 14 mm Xmax and 28.87 Hz free-air resonance, it is engineered for bass reproduction in appropriately designed sealed or ported enclosures. Its 87.6 dB sensitivity provides a useful reference when planning amplifier power and system output.

Cerwin Vega equips this subwoofer with a heavy-duty aluminum cast frame, oversized spider, elevated motor structure, and black-coated 3-inch voice coil. The motor includes a shorting ring intended to reduce distortion, while the elevated structure supports cooling. Klippel DA optimization is also specified for motor and suspension symmetry.

For enclosure-based upgrades, the manufacturer and retailer specifications identify both sealed and ported applications. A 4.0 cubic-foot sealed enclosure or 5.0 cubic-foot ported enclosure is listed as an optimum starting point. Confirm enclosure net volume, amplifier output, wiring load, and available mounting depth before installation.

Key Features

• 1,500W RMS Power Handling: Supports high-power car-audio systems when paired with an appropriately matched amplifier.
• Dual 2-Ohm Voice Coils: Provides 1-ohm or 4-ohm nominal wiring flexibility for compatible amplifiers.
• 15-Inch Woofer: Offers large cone area for dedicated low-frequency reproduction in a custom enclosure.
• 3-Inch Black-Coated Voice Coil: Built for higher thermal capability during demanding use.
• Shorting Ring: Helps reduce distortion as part of the motor design.
• Aluminum Cast Frame: Provides a rigid foundation for the motor, cone, and suspension assembly.

Design & Installation

The VMAX15D2 combines a heavy industrial-strength aluminum cast frame with a black patterned treated semi-pressed pulped cone, treated foam surround, oversized spider, and polished bumped backplate. Oversized polished black chrome terminals support speaker-wire connections. The elevated motor structure is designed to aid cooling, and the single-stacked magnet motor has a 7.89-inch magnet diameter.

Plan for a 13.98-inch mounting cutout and at least 7.48 inches of mounting depth, plus room for wiring and enclosure clearance. Cerwin Vega specifies a 4.0 cubic-foot optimum sealed box and 5.0 cubic-foot optimum ported box; enclosure displacement should also be considered. Use an external amplifier matched to the subwoofer's RMS rating and to the final voice-coil wiring load.
