Warzone WZ46PTi 4x6" 2-Way Coaxial Speakers

The Warzone WZ46PTi is a pair of 4x6-inch two-way coaxial car speakers designed for compact factory-speaker replacement locations. It combines a woofer and tweeter in each speaker, allowing a single mounting position to reproduce midrange and high-frequency detail. This format is suited to vehicle audio upgrades where space and mounting depth are limited.

With a 4-ohm nominal impedance, the WZ46PTi is intended for use with compatible car stereo speaker outputs or an appropriately matched amplifier. The pair is rated for 100 watts RMS total system power and 380 watts maximum total system power. Its 90 dB sensitivity specification supports useful output from modest-power systems when installed and powered correctly.

The speaker uses a glass-fiber woofer cone supported by a 10-ounce ferrite woofer magnet. This woofer construction is paired with a 44 mm PEI dome tweeter using an NdFeB magnet. The two-way arrangement is specified with a 5 kHz tweeter crossover point.

Warzone lists an 85 Hz to 20 kHz frequency response for the WZ46PTi. Its sound profile is designed to cover the upper bass, midrange, and treble range handled by a compact coaxial speaker. For deeper low-frequency output, it can be used as part of a broader system that adds a properly matched subwoofer.

Installation dimensions are important for 4x6-inch speaker replacements because factory openings vary by vehicle. The listed cutout measures 3.26 by 5.52 inches, while mounting depth is 1.66 inches and overall height is 2.45 inches. Confirm the vehicle opening, clearance behind the mounting surface, wiring polarity, and mounting-hole pattern before purchase.

Key Features

• 4x6-Inch Coaxial Format: Combines woofer and tweeter in each compact speaker.
• Two-Way Design: Separates woofer and tweeter frequency duties within each speaker.
• 100W RMS System Rating: Supports power matching with compatible audio equipment.
• Glass-Fiber Woofer Cone: Provides the specified woofer diaphragm material.
• 44 mm PEI Dome Tweeter: Handles high-frequency reproduction in the coaxial assembly.
• Compact Mounting Depth: A 1.66-inch depth helps with space-conscious installations.

Design & Installation

The WZ46PTi uses a glass-fiber woofer cone, a 10-ounce ferrite woofer magnet, and a PEI dome tweeter with an NdFeB magnet. Its integrated coaxial layout places the tweeter over the woofer, reducing the space required compared with separate component speakers. The specified 5 kHz crossover directs higher frequencies to the tweeter.

Use the WZ46PTi where the vehicle accepts a 4x6-inch speaker and where the listed 3.26 by 5.52-inch cutout, 1.66-inch mounting depth, and 2.45-inch overall height can be accommodated. Match the speakers with a 4-ohm-compatible source unit or amplifier and observe correct positive and negative terminal polarity. The available product information confirms a speaker pair, but does not confirm included grilles, wiring adapters, or mounting hardware.
