CERWIN VEGA 800 Watts 4 Ohms/400 Watts Power Handling Max 10-Inch Dual Voice Coil

Features:

• 1,100w Max
• 400watts Rms
• Proprietary Stamped Cast Vega Basket Design
• Optimized High-power Single-stacked Motor Structure
• Double-stitched Vega Red Santoprene Surround

Details: Proprietary Stamped Cast Vega Basket Design Optimized High Power Single-Stacked Motor Structure Parabolic One Piece Stamped Carbon Fiber Polypropylene Cone Double Stitched Vega Red Santoprene Surround Proprietary Horizontal Mounted Spring Loaded Terminals High Power Integrated Impedance Selector Vega Concealed Mounting Gasket Total Diameter (A) 10.7 Inch 272 mm Mounting Diameter (B) 8.82 Inch 224 mm Screw Hole Diameter (C) 0.7 Inch 18 mm Mounting Depth (D) 5.43 Inch 138 mm Magnet Diameter (E) 5.63 Inch 143 mm THIELE/SMALL PARAMETERS SPL (dB) 85.5 Re (Ohms) [series] 4.0/4.0 Qms 6.1 Qes 0.66 Qts 0.602 Fs (Hz) 34.5 Vas (L) 28 Cms (mm/N) 0.37 Mms (g) 118 Sd (m2) 0.033 BL (T M) 15.3 Xmax (mm) 17 INTEGRATED IMPEDANCE SELECTOR To help installation we at Cerwin-Vega Mobile designed a simple but effective single terminal Dual Voice coil setup. Simply pull out the terminal and rotate it to the impedance desired. The impedance above the terminal is now the impedance of the driver, with only one set of speaker wires going to it. No complicated wiring anymore!!!

Model: V104D-Parent

Binding: Wireless Phone Accessory
